xTool P2 Laser Cutter Bundles
High-powered laser cutting for advanced hobbyists, bundled with all the accessories you need to complete your setup
The 55W CO2 laser delivers powerful, precise cuts—slicing 0.71" basswood and 0.79" acrylic (even transparent) with ease. It’s 500% faster than diode lasers, minimizing edge blackening. With the largest bed size in desktop lasers and up to 118" AutoPassthrough, it's ideal for large-scale projects. It also engraves on wood, acrylic, leather, glass, and metal directly.
Features
-
55W Power: 500% faster than 40W diode laser machines when cutting 20mm acrylic & 18mm wood in one pass.
-
16MP Dual HD Camera: preview your design in real-time and spot tiny details, ensuring error-free results.
-
AutoPassthrough™: Automatically processes materials up to 118'' long for larger projects.
-
3D Curve™ Engraving: Seamlessly engrave on curved surfaces.
-
Distimaster™ Ranging System: 100% autofocus and distance measurement precision within 0.001”, ensuring accurate cut-through every time.
Benefits
-
Work on larger projects: with its large bed size (23.6” x 12”), AutoPassthrough™ feature, and high speed this laser is perfect for larger projects and materials
-
Variety of applications: great for wood, jewelry, signmaking, and more. Plus, can cut acrylic in any color!
-
Ease of use: Simply place the material, press the button, and admire your work! Plus, xTool’s software makes it easy to create stunning designs with no design experience.
-
Prioritizing safety: Auto-lock, emergency stop, enclosed design, warning systems, and excellent smoke exhaust system
What's Included
- 1*xTool P2 Laser Cutter
- 1*46 USB data cable (type-C)
- 5*3.5mm Cardboard
- 1*Funnel
- 1*Antifreeze
- 1*L-shaped wrench
- 1*Screwdriver
- 4*Basswood Plywood 3mm
- 1*Exhaust pipe assembly
- 1*Power cord
- 2*Transparent acrylic
- 1*Quick Start Guide
- 1*Instructions for use
- 1*xTool Safety Set with Sensors V1.5
Specifications
Class IV vs. Class I - Differences in Safety
Safety Class |
Class I |
Class IV |
Who it's great for |
Users prioritizing safety over efficiency (ie: Schools) |
Most users |
Lid open detection |
✓ |
X |
Base plate detection |
Operation only allowed/started if base plate is installed |
X |
Cylinder engraving |
Up to 42mm diameter |
Up to 180mm diameter |
Slide-through door |
X |
✓ |
Feeding accessories |
X |
✓ |
Machine Specifications
-
Rated Power: 55W(CO₂ Glass Laser Tube)
-
Product Size: 39.4"×25.1"×10.6" (1000×639×268mm)
-
Product Weight: 45KG
-
Max. Carving Speed: 600mm/s
-
Processing Precision: 0.01mm
-
Z-axis Movement: 3"(75mm)
-
Bed Size: 26.7''×14.1''(680x360mm)
-
Working Space: 23.6"×12" (600×305mm)
-
Max. Workpiece Height: With tray 2.5"(64mm), Without tray 2.7"(71mm), With riser base 8.5"(215mm)
-
Rotary engraving diameter: With riser base 0-180mm, Without riser base 3-50mm
-
Operating Ambient Temperature*: 10-30°C (10-86°F)
-
Storage Temperature*: 10-45°C (50-113°F)
- *If the temperature drops below 10°C (50°F), please add antifreeze under the guidance in the user manual.
AI Camera Specifications
-
Camera: Panoramic camera + close-range camera
-
Number of Pixels (Effective): 16MP×2
-
Vision Precision: 0.3mm
-
Image Resolution: 1000DPI
-
Focus Mode: Autofocus
Accessory Specifications
-
Water-cooling System Capacity: 1.4L(0.37gal)
-
Air Assist (adjustable): 15-150 kPa
-
Exhaust Fan: 145CFM
Software and Connection Specifications
-
Operating Systems: Android / iOS / iPad / Windows / MacOS
-
Control Software: xTool Creative Space / LightBurn
-
Supported File Types: SVG, DXF, JPG, JPEG, PNG, BMP
-
Connection / Transmission: Wi-Fi, USB, Ethernet
